Friday, June 3, 2011

2D version download link



This is 2D version of the model in the previous post
앞의 포스트에 올린 모델의 2d 버전 링크입니다.

When you insert numbers in the Component Options window, you can change the number of copies of circles and the spacing between the circles.
콤포넌트 옵션 윈도우에 적당한 숫자를 입력하면 복사되는 원의 개수나 간격을 조정할 수 있습니다.

But don't insert too large number in the 'number of copies of circles' blank. For instance number 35 will take 5 minutes or more to configure.
그런데 너무큰 숫자를 입력하지 않는 것이 좋습니다.
일반적인 경우 복사 개수에 35만 입력해도 5분 이상 걸릴 수 있습니다.

 Enjoy!





*You can find Component Options window below the window menu of SketchUp
and when select the downloaded component, you can also find at context menu.
혹시나..콤포넌트 옵션 윈도우는 스케치업 메뉴의 윈도우 항목 아래에 있습니다.
다운로드한 콤포넌트를 선택한 상태서 우클릭하면 메뉴에 나타나기도 합니다.

Thursday, June 2, 2011

Transformation of single object(sphere) by DC of SketchUp

In this post you can see another possibility of Dynamic Components of SketchUp.

As Dynamic Component supports only transformation in length(3 directional),
we need much imagination to transform objects with DC as the way we want.

In case of transformation of sphere, this post will help you.


Left below you can see the original sphere@@
and transformation of this sphere along with each axis.










--------------------------------------Behind the scene---------------------------------------

Actually this is not a transformation of 'single' object.
As you see below each sphere consists of 8 pieces :0






The idea is very simple.
Set the formulas of  lengths of 4 pieces of sphere in each direction to be same
along with the axis where they are placed.
For example 4 pieces of + X direction(red axis) should have same LenX each, and the other 4 pieces of -X direction also have another same LenX each, and so on...

The only(big) problem is that this method is only applicable to sphere (yet), not to everything else ;(







--------------------------------------Down load 2D version---------------------------------------


http://taekle.blogspot.com/2011/06/2d-version-download-link.html

Spiral Ramp study by DC of SketchUp

 A spiral which is variant in height, radius, depth of slabs and even center points.





the original dynamic component model

Thursday, May 26, 2011

Wednesday, November 3, 2010

Skyscraper study by DC parametric modeling







Regular but deformed surface using dynamic component + loft by splines plugin 에서 사용한 수식을 약간만 손봐서 원형의 변화있는 볼륨을 만들었다. 스크린샷에서 보듯이 원래의 수식은 거의 그대로이고(더욱 변화 있는 굴곡을 위해서 상수 몇개를 손보기는 했다) 직선으로 배열하던 수식을 원형배열을 하는 수식으로 교체해서 위로 올라가면서 변화하는 형태를 완성.
자 상상력을 조금만 더 발휘해보자..
